FCC1814 Series Common Mode Chokes
FCC1814 Type Power Line Chokes with Frame Core and Base
FEATURES:
·Core Size: FC1814
·Rated Current: 0.45~1.6A
·Insulation voltage: 1500VAC,2S(line-line)
·Rated voltage: 250VAC max@40°C
·High inductance with low resistance
·Closed magnetic circuit with frame construction
·Excellent differential-mode suppression, high pulse-handing capability
Current-compensated Frame Core Double Choke Coils
Current-compensated Frame Core Power Line Chokes
Frame Core Current-compensated Common Mode Choke Coils
FCC1814 Type Power Line Chokes with Frame Core and Base
Applications：
*Suppression of common-mode and differential-mode interferences
*Electronic ballasts for lamps
*High power switch-mode power supplies for consumer electronics
