FCC0810 Series Common Mode Chokes
FCC0810 Type Power Line Chokes with Frame Core and Base
FEATURES:
·Working frequency: high frequency
·Core: Ni-zn
·Size: 08*10 series
·Shape: Horizontal
·High inductance with low resistance
·Excellent differential-mode suppression, high pulse-handing capability
Current-compensated Frame Core Double Choke Coils
Current-compensated Frame Core Power Line Chokes
Frame Core Current-compensated Common Mode Choke Coils
FCC0810 Type Power Line Chokes with Frame Core and Base
Frame core power line choke provides exceptional common-mode suppression and exceptional stray inductance to suppress differential-mode noise. In effect， the FCC series combines the features of two separate components into one. They are compact in size and are available in the either vertical configuration, using minimal board area, or horizontal configuration for low profile applications. They are frequently used in LED lighting, electronics ballast and switch -mode power supplies.
