DP1010 Series Shielded Power Inductor for Digital Amplifier

DP1010 Series Shielded Power Inductor for Digital Amplifier

  • FEATURES:

    ·•Special magnetic shielding structure
    ·•Strong anti-interference ability
    ·•Small size, low noise and low radiation
    ·•High current, low DC resistance
    ·•Wide frequency range, small parasitic capacitance
    ·•Best design with high sound quality and low distortion


    Download file

    FEATURES:

    • Special magnetic shielding structure
    • Strong anti-interference ability
    • Small size, low noise and low radiation
    • High current, low DC resistance
    • Wide frequency range, small parasitic capacitance
    • Excellent heat resistance, easy to weld
    • Best design with high sound quality and low distortion
    • Lead-free product, UL / CE / ROHS compliant



    APPLICATIONS:

    Audio equipment, LCD television set notebook PC, OA equipment digital camera, portable communication equipment, DC-DC converter, etc.



    PART NO. INDUCTANCE DCR (MAX) ISAT(MAX) IRMS(MAX)
    DP1010-3R3M 3.3±20% 19.0mΩ 18.0 5.0
    DP1010-4R7M 4.7±20% 19.0mΩ 11.0 5.0
    DP1010-6R8M 6.8±20% 19.0mΩ 9.7 5.0
    DP1010-8R2M 8.2±20% 19.0mΩ 6.8 5.0
    DP1010-100M 10±20% 19.0mΩ 5.6 5.0
    DP1010-120M 12±20% 22.0mΩ 5.0 4.8
    DP1010-150M 15±20% 36.0mΩ 4.6 3.5
    DP1010-220M 22±20% 36.0mΩ 3.0 3.5
