DP1013 Series Shielded Power Inductor for Digital Amplifier
DP1013 Series Shielded Power Inductor for Digital Amplifier
FEATURES:
·•Special magnetic shielding structure
·•Strong anti-interference ability
·•Small size, low noise and low radiation
·•High current, low DC resistance
·•Best design with high sound quality and low distortion
FEATURES:
- Special magnetic shielding structure
- Strong anti-interference ability
- Small size, low noise and low radiation
- High current, low DC resistance
- Wide frequency range, small parasitic capacitance
- Excellent heat resistance, easy to weld
- Best design with high sound quality and low distortion
- Lead-free product, UL / CE / ROHS compliant
APPLICATIONS:
Audio equipment, LCD television set notebook PC, OA equipment digital camera, portable communication equipment, DC-DC converter, etc.
| PART NO. | INDUCTANCE | DCR (MAX) | ISAT(MAX) | IRMS(MAX) |
| DP1013-3R3M | 3.3±20% | 11.0mΩ | 12.0 | 5.1 |
| DP1013-8R2M | 8.2±20% | 16.0mΩ | 7.5 | 4.4 |
| DP1013-100M | 10.0±20% | 18.0mΩ | 7.1 | 4.2 |
| DP1013-120M | 12.0±20% | 20.0mΩ | 6.0 | 4.0 |
| DP1013-150M | 15.0±20% | 23.0mΩ | 5.3 | 3.8 |
| DP1013-180M | 18.0±20% | 23.0mΩ | 4.6 | 3.8 |
| DP1013-220M | 22.0±20% | 38.0mΩ | 4.3 | 3.0 |
