DP1615 Series Shielded Power Inductor for Digital Amplifier

DP1615 Series Shielded Power Inductor for Digital Amplifier

  • FEATURES:

    ·•Special magnetic shielding structure
    ·•Strong anti-interference ability
    ·•Small size, low noise and low radiation
    ·•High current, low DC resistance
    ·•Best design with high sound quality and low distortion
    ·•Lead-free product, UL / CE / ROHS compliant


    Download file

    FEATURES:

    • Special magnetic shielding structure
    • Strong anti-interference ability
    • Small size, low noise and low radiation
    • High current, low DC resistance
    • Wide frequency range, small parasitic capacitance
    • Excellent heat resistance, easy to weld
    • Best design with high sound quality and low distortion
    • Lead-free product, UL / CE / ROHS compliant



    APPLICATIONS:

    Audio equipment, LCD television set notebook PC, OA equipment digital camera, portable communication equipment, DC-DC converter, etc.

    PART NO. INDUCTANCE DCR (MAX) ISAT(MAX) IRMS(MAX)
    DP1615-100M 10.0±20% 12.0mΩ 15.0 6.4
    DP1615-150M 15.0±20% 22.6mΩ 11.0 5.2
    DP1615-220M 22.0±20% 31.0mΩ 10.0 3.8
