DP1495F Series Shielded Power Inductor for Digital Amplifier
DP1408F Series Shielded Power Inductor for Digital Amplifier
FEATURES:
·•Special magnetic shielding structure
·•Strong anti-interference ability
·•Small size, low noise and low radiation
·•High current, low DC resistance
·•Best design with high sound quality and low distortion
FEATURES:
- Special magnetic shielding structure
- Strong anti-interference ability
- Small size, low noise and low radiation
- High current, low DC resistance
- Wide frequency range, small parasitic capacitance
- Excellent heat resistance, easy to weld
- Best design with high sound quality and low distortion
- Lead-free product, UL / CE / ROHS compliant
APPLICATIONS:
Audio equipment, LCD television set notebook PC, OA equipment digital camera, portable communication equipment, DC-DC converter, etc.
| PART NO. | INDUCTANCE | DCR (MAX) | ISAT(MAX) | IRMS(MAX) |
| DP1495F-4R7M | 4.7±20% | 6.0mΩ | 21.0 | 14.0 |
| DP1495F-6R8M | 6.8±20% | 6.5mΩ | 17.0 | 12.0 |
| DP1495F-8R2M | 8.2±20% | 7.5mΩ | 16.0 | 11.0 |
| DP1495F-100M | 10.0±20% | 8.5mΩ | 15.0 | 10.0 |
| DP1495F-120M | 12.0±20% | 8.5mΩ | 11.5 | 10.0 |
| DP1495F-150M | 15.0±20% | 8.5mΩ | 9.5 | 10.0 |
| DP1495F-220M | 22.0±20% | 15.5mΩ | 9.0 | 7.0 |
| DP1495F-330M | 33.0±20% | 15.5mΩ | 6.2 | 7.0 |
