FEATURES:

• Simple structure
• High inductance accuracy
• Small distributed capacitance
• High self-resonant frequency
• Small temperature coefficient
• Good stability and strong anti-interference ability
• Accept customer’s special specifications
• Available in bulk packaging, blister tray packagingand taping packaging

• Special peeling and soldering processes
• RoHS compliant and halogen free
• Working temperature: -40 degrees to +125 degrees
• UL or PVC heat shrinkable sleeve protection

APPLICATIONS:

Widely used in smart wearable devices, wireless charging devices, induction devices, communication devices, speaker equipment, hearing aids, car accessories, electric toys, massage chairs and other fields.

HOW TO ORDER:

① Type: ACR(Air Coil Round Wire Winding), ACF(Air Coil Flat Wire Winding)

② Wire Gauge: 0.8mm

③ Internal Diameter: 5.0mm

④ Turns: 8.5T

⑤ Lead length: 7.0mm

⑥ Winding direction: R is Clockwise, L is Count
